HEC-T Residential Energy Storage System
HEC-T Residential Storage System

HEC-T Residential Energy Storage System


Hiconics's HEC-T Home battery storage split phase model has following features: Systematic design, in-depth optimization and seamless connection with Hiconics Hybrid inverter; Better stability: Safest type of LifePO battery, an adoption of high-performance processors, international brand devices; Unique battery heating technology, which is capable to work at low temperature; Long life cycle, more than 6000 times; Safety Cert. : TUV, CE, UL, UN38.3, and so on; Remote fault diagnosis, upgrade, and maintenance; Auto power replenishment technology is adopted to prevent battery over-discharge; Multiple communication interfaces: RS485, CAN.

Contact us


Products

Technical Parameters of HEC-T Residential Storage System

Nominal voltage [V]204.8
Operating voltage range [V]180-232
Total energy [kWh]6.1
Usable energy [kwhl5.5
Rated capacity [Ah]30
Standard power [kW]5.1
Max. power [kWI6.1
Recommend charge/discharge current [A]25
Max, charge/discharge current [A]30
Battery roundtrip eifciency0.95
Cycel life[ 90% DOD]6000 Cycles
Expected life time / Warranty [year]5
Available charge/discharge temperature range [°C]-30 to 50
Storage temperature [°C]-20 to 50(3months) 0 to40(1 year)
Humidity [%]0-100
Altitude [m]Below 3000
Degree of protectionR$485/CAN2. 0
Battery to inverterIP65
Battery to battery/BMSCAN2.0
Master control capacity indicatorALEDX25%,50%6.75%,100%)
Master control LED indicator [Working mode]ILED
System switch [on/off]Button 1+ Breaker*1
CertiffcateCE/IEC62619/UN38.3/IEC62040/UKCA
Hazardous materials classificationClass9
Dimensions[WxHxD] [mm]MC0600:482.5°173.5*153
HV10230:482.5*471 5*153
WeightMC0600: 75kg
+2* HV10230: 69kg
